PLUS D’INFORMATIONS
| Cadre | Carbone : Teammachine SLR 01 Premium Carbon with Aerocore Design, ICS Technology, Integrated Aerocore Bottle Cages, Stealth Dropout Design, TCC Race compliance level, PF86 bottom bracket, 12×142 mm thru-axle, Tire clearance: 30 mm (Measured Width) |
| Fourche | Carbone : Teammachine SLR 01 Premium Carbon, ICS Technology, Stealth Cable Routing, TCC Race Compliance Level, Stealth Dropout Design, Flat Mount Disc, 12×100 mm Thru-Axle, 48 mm offset (Size 47-51), 43 mm offset (Size 54-61) |
| Manette de dérailleur | Campagnolo Super Record EPS, 2x12v |
| Dérailleur avant | Campagnolo Super Record EPS |
| Dérailleur arrière | Campagnolo Super Record EPS 12v |
| Cassette | SANS CASSETTE |
| Chaîne | Campagnolo 12v |
| Pédalier | Campagnolo Super Record Carbon 175mm, 53-39 |
| Boîtier de pédalier | PF86 |
| Freins | Campagnolo Super Record Hydro |
| Roues | SANS ROUES |
| Pneus | SANS PNEUS |
| Guidon | ICS Carbon, One-Piece Full Carbon Cockpit, 67 mm reach, 127 mm drop, 40 cm largeur |
| Potence | ICS Carbon, One-Piece Full Carbon Cockpit, -12.5° 130mm |
| Selle | Fizik Arione Carbone |
| Tige de selle | Teammachine SLR 01 Premium Carbon D-Shaped Seatpost, 15 mm Offset |
| Poids | 6.70 kg |
| Poids maximum | 110 kg : le poids maximum du système comprend le vélo, le cycliste et les équipements |
| Coloris | Team Ag2r |
| Taille de cadre (cm) | 47 | 51 | 54 | 56 | 58 | 61 |
| Tube de selle (mm) | 423 | 468 | 504 | 524 | 545 | 574 |
| Tube supérieur (mm) | 517 | 534 | 549 | 559 | 574 | 589 |
| Longueur base (mm) | 410 | 410 | 410 | 410 | 410 | 410 |
| Douille de direction (mm) | 110 | 130 | 145 | 165 | 184 | 210 |
| Angle de direction (°) | 71.5 | 71.5 | 72.3 | 72.3 | 72.3 | 72.3 |
| Angle tube de selle (°) | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 | 73.5 |
| Empattement (mm) | 968 | 986 | 989 | 1000 | 1015 | 1030 |
| Stack (mm) | 506 | 530 | 550 | 565 | 584 | 608 |
| Reach (mm) | 367 | 377 | 386 | 392 | 401 | 409 |
| Longueur potence (mm) | 90 | 100 | 100 | 110 | 110 | 120 |
| Largeur cintre (mm) | 400 | 420 | 420 | 420 | 420 | 420 |
| Déport fourche (mm) | 48 | 48 | 43 | 43 | 43 | 43 |
| Longueur manivelles (mm) | 170 | 170 | 172.5 | 172.5 | 175 | 175 |
Caractéristiques
| Genre | Homme |
| Taille de Roues | 700mm |
| Groupe | Campagnolo Super Record EPS 12V |
| collection | 2021 |
| Équipement | Cadre Carbone Freins à Disques Fourche Carbone Passage de Gaines Interne |
